ProFi-Scale
Integrated weighing system for milling processes
PowerMill CW-250
PowerMill CW-250
The PowerMill CW-250 is a high-performance, high-quality conical sieve mill that is used for deagglomerating and sizing granular products to a fineness of 150 µm.
Thanks to it's compact and modular design, the PowerMill CW-250 is easy to integrate in complete process plants. With it's extraordinary diversity and high performance, this conical sieve mill can be used in any demanding milling process, whether for achieving optimum grain size distribution or high flow rates, as well as for milling temperature-sensitive products, or potentially explosive substances.
Suitable for the following industries :
PHARMACEUTICAL
BATTERY
CHEMICAL
FOOD
Process Characteristics
Particle size range
5 cm - 150 µm
Throughput
2000 - 5000 kg/h
Product density
up to 2 kg/dm³
Temp. range of product
from -20°C to 60°C
Executions
Standard
- Certified ATEX construction for Zone 0/20
- WIP
Options
- MIE range down to > 1 mJ
- CIP
- SIP
Dimensions & Weight
| Length | 1309 mm |
| Width | 860 mm |
| Height | 1355 mm |
Materials
Exterior
AISI-304 /304L - Ra ≤1.4 μm
Interior
AISI-316 /316L - Ra ≤ 0.8 μm
In product contact, certified by FDA
EPDM/PTFE/Silicone
Features and information
•
Very broad scope of application ranging from all types of dry to wet and sensitive powders
•
Diverse use possibilities ranging from stand-alone and in-line to integration in complete plants
•
Clear GMP-capable concept for smooth, reproducible production
•
High level of production safety thanks to certified ATEX construction for Zone 0/20
•
High level of operational safety for containment requirements up to OEB 5 (< 1µg/m3)
•
Easy and quick cleaning Washing-in-Place (WIP)
