FlexMill-Lab OW-1

FlexMill-Lab OW-1

FlexMill-Lab OW-1

The oscillating and rotating FlexMill-Lab OW-1 sieve mill is used for the gentle milling and deagglomeration of heat-sensitive and difficult-to-process products to a fineness of 250 µm.
Ideal for processing small-scale laboratory batches of 50 g to 1 kg, the flexibility of the FlexMill-Lab OW-1 permits itself to be used for pilot-scale quantities due to its production rate of 30 - 100 kg/h and the scale-up guarantee to our FlexMill production equipment. The device's compact design facilitates easy integration and a quick set-up in any laboratory.

Suitable for the following industries :

Industry of type PHARMACEUTICAL

PHARMACEUTICAL

Industry of type BATTERY

BATTERY

Industry of type CHEMICAL

CHEMICAL

Industry of type FOOD

FOOD

Process Characteristics

Size reduction range
Size reduction range

20mm - 250μm

Productivity
Productivity

50g -120kg/h

Temp. range
Temp. range

-20°C to + 60°C

Product density
Product density

up to 2kg/dm³

Dimensions & Weight

Dimensions & Weight
Dimensions & Weight
Length 932 mm
Width 566 mm
Height 749 mm

Materials

Materials

Exterior

AISI-304 /304L - Ra ≤1.4 μm

Interior

AISI-316 /316L - Ra ≤ 0.8 μm

In product contact, certified by FDA

EPDM/PTFE/Silicone

Features and information

• Scale-up guarantee with our production equipment, FlexMill
• Milling heads easily interchangeable on a single Tri-Clamp flange
• Light and compact milling heads (~ 10 kg)
• Different rotor and sieves types for wet and dry milling
• Quick, efficient and user-friendly cleaning
• Possibility to sterilize the milling heads
• Milling heads available in ATEX zone 1-21
